Pneumatic Butterfly Valve, ASTM A536 65-45-12, 36 IN, 150 LB

Key Specifications / Features

The Pneumatic Butterfly Valve, manufactured in China, features a durable ASTM A536 Grade 65-45-12 body and an ASTM A351 Grade CF8M disc. With a 36-inch (DN900) size, Class 150 LB rating, and an EPDM seat, it ensures reliable sealing and performance. Designed with RF ends, this valve is ideal for efficient flow control in large-scale industrial applications.

Model No.: LD-20250102-BFV-01
Hits: 1
Categories: Butterfly Valves
Tags: Pneumatic Actuated Butterfly Valve, ASTM A536 Grade 65-45-12 Butterfly Valve, 36 Inch Butterfly Valve

Request a quote

Detail Information

Product Item: DI Butterfly Valves, Pneumatic Cylinder Actuator
Size: 36 Inch, DN900
Pressure: Class 150 LB
Connection End: RF ASME B16.47A
Body Material: ASTM A536 Grade 65-45-12/Ductile Iron Material
Disc Material: ASTM A351 Grade CF8M
Stem Material: ASTM A582 Grade 416
Shaft Seal Material: Buna N
Seat Material Material: EPDM
Bearing material: Lubricant Impregnated Bronze
Leakage Class: API 598
Operation: Pneumatic Cylinder Actuator
